150 mm
ISO 17631 A.2.22 (I) Fixed fire extinguishing inergen bottle, placed in protected area sign — Fire Control Plan (ISO 17631) safety pictogram
150 mm
Shown at the size selected
Fire Control Plan (ISO 17631)

Fixed fire extinguishing inergen bottle, placed in protected area

ISO 17631 A.2.22 (I)

Marks a fixed fire-extinguishing bottle charged with inergen that stands inside the protected area, the gas being shown by the letter and colour in the symbol. Draw it on the fire control plan at the position of the bottle within the space it protects.

Size

Material

Priced on your quotation, with the rest of your RFQ list.

Specifications

StandardISO 17631
ReferenceA.2.22 (I)
FamilyFire Control Plan (ISO 17631)
Base size150 × 150 mm

Available materials

  • Photoluminescent Adhesive
  • PVC Adhesive
  • Photoluminescent Face Mounted on Polycarbonate
  • PVC Face Mounted on Polycarbonate
