Sprinkler-Section Valve
SIS036 · ISO 24409
Identifies sprinkler-section valve as part of the shipboard fire control plan symbol set. Mark on the fire control plan at the location of the equipment or feature concerned. Also catalogued under IMO Resolution A.952(23) for use on SOLAS-compliant vessels.
Specifications
| Standard | ISO 24409 |
| Reference | SIS036 |
| Category | Fire Control Plan (ISO 17631) |
| IMO | A.952(23) |
| Base size | 150 × 150 mm |
Available Materials
- Photoluminescent Adhesive
- PVC Adhesive
- Photoluminescent Face Mounted on Polycarbonate
- PVC Face Mounted on Polycarbonate
